Telguard TGHC-CAM2 Indoor HD Video Camera



The Telguard TGHC-CAM2 Indoor HD Video Camera integrates seamlessly with Telguard HomeControl, adding video to the security system for any home or business. With the TGHC-CAM2 you can remotely view event-triggered clips or images, or real-time streaming video on your smartphone or computer. This small and sleek wireless IP Camera with IR (infrared) illumination allows for indoor use in both daylight and low-light environments. The camera accomplishes this by automatically providing extra IR illumination when enough visible light is not available for proper operation. Network connectivity can be provided through either a hardwired or wireless IP connection to your home or business network connection.

FOR: RESIDENTIAL

PRODUCT FEATURES

  • Delivers Excellent 720p HD Video.
  • High-Definition Camera Offers Exceptional Clarity Allowing Customers to Review Video and Pictures In Detail.
  • Faster Network Performance with 802.11n Wireless Connection or 10/100 Base-T Ethernet.
  • Video Algorithm Motion Detection.
  • Built-In Infrared LEDs for Night Time Illumination.
  • Simplified Wireless Network Setup with WPS Function.

Camera Specifications:

Sensor and Lens

  •  Lens: Fixed-Focus Lens Aperture: F2.4, Diagonal View Angle: 90°.
  •  Image Sensor: 1/4” CMOS Sensor.

Video

  • Cameras: Day / Night Vision with Active IR Illumination (0 Lux).
  • Resolution: 720p HD (1280 x 720).

Network Interface

  • Ethernet 10/100 Base-T (RJ45).
  • 802.11n (2×2) Wi-Fi backwards compatible with 802.11b/g.

Power

  • Input: 100-240VAC, 50-60Hz.
  • Output: 12VDC, 1A.

Physical Details:

  • Dimensions: 2.56” H x 2.56” W x 1.34” D (65mm H x 65mm W x 34mm D).
  • Weight: 3.5 oz. (98g).
  • Operating Environment: Temperature – 32 to 104 °F (-0 to 40 °C) Humidity – 80% Relative Humidity (non-condensing).
  • Compliance: UL, ULC, FCC and CE.

For more Telguard Products Click Here

Telguard TGHC-CAM1 Indoor Outdoor Video Camera

The Telguard TGHC-CAM1 Indoor Outdoor Video Camera integrates seamlessly with Telguard HomeControl, adding video to the security system for any home or business. With the Telguard HomeControl Camera you can remotely view event-triggered clips or images, or real-time streaming video on your smartphone or computer. This small and sleek wireless IP Camera with IR (infrared) illumination allows for indoor and outdoor use in both daylight and low-light environments. The camera accomplishes this by automatically providing extra IR illumination when enough visible light is not available for proper operation. Network connectivity can be provided through either a hardwired or wireless IP connection to your home or business network connection.

The TGHC Camera allows you to add the View option easily and cost effectively to Telguard HomeControl’s Interact and Control service packages. Access to real-time streaming or video clips gives your customers additional peace of mind and security.

FOR: RESIDENTIAL

PRODUCT FEATURES

  • Fully integrates with Telguard HomeControl Automations and Alerts.
  • Compact, Weather Resistant IP Camera, IP54 Dust and Water Resistant.
  • Powered using DC or PoE. Dual Image Sensors for Day/Night Vision, Active IR Illumination.
  • PIR Motion Sensor.
  • VGA Resolution (640×480) up to 30fps.
  • IEEE 802.11n Wireless and 10/100 Base-T Ethernet

Camera Specifications:

Sensor and Lens

  • Lens: Fix Focus Lens, Aperture: F2.0 Diagonal View Angle: 60°.
  • PIR Sensor: Built-in PIR (Motion Trigger) Detection Range 15 feet (5 Meters)

Video

  • Cameras: Dual Image Sensors for Day / Night Vision, Active IR Illumination and PIR Motion Sensor.
  • Resolution: VGA Resolution (640 x 480) up to 30 fps

Network Interface

Ethernet 10/100Base T (RJ45) or Wi-Fi B/G/N Internet connection with Wi-Fi Tunneling.

Power

• Power Supply: 12V/1A, 100-240VAC.

• Consumption: 12V DC, Max 5.8W

Physical Details:

  •  Dimensions: 2.83” H x 2.83” W x 1.10” D 72mm H x 72mm W x 20mm D.
  •  Weight: 0.18 lbs. (84g)
  • Operating Temperature: -20 to 45 °C (-4 to 113 °F)

NOTE: Must be above 0 °C (32 °F) for start-up.

  • Humidity: 5-93% Relative Humidity (non-condensing).
  • IP Rating: Compact, Weather Resistant IP Camera, IP54 Dust/ Water Resistant.

For more Telguard Products Click Here

Telguard VML4030-1T9NAS Arlo GO Mobile HD Video Camera

The Telguard VML4030-1T9NAS Arlo GO Mobile HD Video Camera System is the world’s first and only LTE, 100% wire-free, weatherproof, mobile HD security camera. It is ideal for RVs, boats, vacation homes or anywhere with Telguard LTE coverage. This low-maintenance and user-friendly LTE video system can be used as a stand-alone video system, and can easily integrate with HomeControl Flex™, Telguard’s interactive solution.

HomeControl Flex Integration

Integrate the Arlo Go Video System with HomeControl Flex. Telguard’s HomeControl Flex interactive solution allows you to integrate the Arlo Go Video System with your customers’ professionally monitored security systems. With HomeControl Flex and an Arlo Go Wire-free HD Camera, enable remote viewing of event-triggered clips, images and live video from anywhere, on a smartphone, computer or tablet.

FOR: RESIDENTIAL AND COMMERCIAL

PRODUCT FEATURES

  • Certified for use on AT&T LTE network.
  • Telguard’s industry renowned customer support.
  • 100% Wire-free, eliminating power cords and wiring hassles.
  • Optional power supply connection.
  • Delivers HD quality (720p) live video. 2-way voice capability.
  • SD card slot for local recording and backup. Weatherproof (IP65), allowing outdoor use.
  • Night vision of up to 25 feet.

Camera Specifications:

  • Dimensions: 3.5 x 2.73 x 3 in (90 x 69.5 x 77.9 mm).
  • Weight: 11.8 oz (335g with battery).
  • Battery Life: Varies based on setting, usage and temperature.
  • Resolution: High Definition (1280×720).
  • Format: H.264.
  • Field of View: 130°.
  • Night Vision: 850 nm LEDs Illuminates up to 25 feet. IR Cut-Off Filter.
  • Imaging Sensor: Full Color CMOs. Auto-Adaptive White/Black Balance and Exposure.
  • Requirements: Arlo Go compatible power adapter and cable (included).

Mobile Connectivity:

  • Requires monthly Telguard LTE service. • U.S. and Canada only.

Weatherproof:

  • Operating Temperature: -4 to 113° F (-20 to 45° C).
  • Water Resistant: IP65 Rating.

Includes:

  • (1) Black outdoor security mount
  • (1) Outdoor mount screw set
  • (1) Quick start guide
  • (1) Window decal
  • (1) Mobile HD security camera
  • (1) Rechargeable battery
  • (1) Power adapter with cable
  • (1) Telguard SIM card

For more Telguard Products Click Here

Telguard VMC4030-1T9NAS Arlo Pro HD Wire-Free Video Camera

The Telguard VMC4030-1T9NAS Arlo Pro HD Wire-Free Video Camera Video System offers a new perspective to home security. The Arlo Wire-free HD Camera breaks the mold of traditional security cameras, and gives users the freedom to install cameras across 100% of their property — indoor or out. The combination of easy installation, battery-operated wire-free design, and waterproof construction makes it a perfect fit for virtually any placement, even in a tree.

HomeControl Flex: Telguard’s Interactive Solution

Telguard’s HomeControl Flex interactive solution allows you to integrate the Arlo Video System with your customers’ professionally monitored security systems. With HomeControl Flex and an Arlo Wire-free HD Camera, enable remote viewing of event-triggered clips, images and live video from anywhere, on a smartphone, computer or tablet.

FOR: RESIDENTIAL

PRODUCT FEATURES

  • 100% Wire-free, eliminating power cords and wiring hassles.
  • Delivers HD quality (720p) live video. 2-way voice capability.
  • Waterproof (IP65), allowing both indoor and outdoor use.
  • Night vision of up to 25 feet. Includes one rechargeable battery.
  • Fast and flexible installation using magnetic mounts.
  • Low maintenance and user-friendly.
  • Can be used as a stand-alone video system, and can easily integrate with HomeControl Flex™, Telguard’s interactive solution.
  • System requires both Arlo Pro Wire-free HD Camera and Arlo Pro Base Station (each sold separately).

Camera Specifications:

  • Dimensions: 3.1 x 1.9 x 2.8 in (79.3 x 48.6 x 70.5 mm).
  • Weight: 11.1 oz (316g).
  • Battery Life: Varies based on setting, usage and temperature.
  •  Resolution: High Definition (1280×720).
  • Format: H.264. • Field of View: 130°.
  • Night Vision: 850 nm LEDs Illuminates up to 25 feet. IR Cut-Off Filter.
  • Imaging Sensor: Full Color CMOs. Auto-Adaptive White/Black Balance and Exposure.
  • Requirements: Arlo Pro Base Station and High-Speed Internet Connection.

Wireless:

  • Frequency: 2.4GHz, 802.11n.
  • Range: 300+ Feet Line of Sight.

Weatherproof:

  • Operating Temperature: -4 to 113° F (-20 to 45° C).
  • Water Resistant: IP65 Rating.

Base Station Specifications:

  • Requirements:

– High-Speed Internet Connection Minimum 1 Mbps Upstream Recommended

– Available Port on Customer’s Router.

  • Dimensions:

-2.3 x 6.9 x 5.0 in (58.6 x 174.5 x 126.5 mm).

  • Weight: 11.1 oz (316g)
