alula RE508XC 8-Zone Commercial Hardwired to Wireless Translator

$119.99

Alula 8-Zone Commercial Hardwired to Wireless Translator *Special Order Item

Share this product

Description

The alula RE508XC 8-Zone Commercial Hardwired to Wireless Translator Converts hardwired intrusion zones to wireless sensors, enabling enrollment to a wireless panel. Universally configurable for multiple sensor-panel combinations. The UL-compliant translators include a 12VDC wall transformer and back-up battery. Also functions as a repeater to increase sensor range and reliability.

Field configurable RF. Just set the dial to the brand of sensor and the brand of panel being installed. You no longer need a specific model set to the specific manufacturers frequency.

FEATURES:

  • Compatible with most sensor brands
  • 8 Hardwire loops, with end-of-line resistor auto-detect
  • Unique wireless ID (or loop) for each zone
  • Unique wireless ID for the device itself
  • 12VDC available to back-up PIRs, glassbreaks and other 150mA (80 mA for UL) sensors
  • Dual antennas increase sensor range and reliability
  • Separate ID’s supervise tamper, power, and low battery

TECHNICAL SPECIFICATIONS:

Physical

8.5 x 5.0 x 1.3 inches

16.0 oz

Cover Opening, Wall Removal

#4 or #6 screws (not included)

32º to 120ºF (0º to 49ºC)

-4º to 86ºF (-20º to 30ºC), Long-Term

85% relative humidity, non-condensing

10.2VDC to 13VDC, 150mA Max

(80mA Max for UL installations)



100-240VAC 50/60Hz 0.5A

12VDC 1A

RE012-6



N/A

6VDC 800mAh NiMH

RE030

8mA

32mA

319.5MHz, 345MHz, 433.92MHz

Cryptix® (Connect+), Interlogix® (formerly GE®), Honeywell®, DSC®, 2GIG®, Qolsys®

N/A



4-wire devices only

NC (Normal Closed) or NO (Normal Open)



4 hours minimum at 80mA 24 hours minimum



None (short)

750 ohm to 15k ohm

None (open)

750 ohm to 15k ohm

1000 feet max

22 AWG min

RE508X:

UL1023, ULC1023

RE508XC:

UL1023, ULC1023, UL1610, ULC S304

FCC, IC

For more Alula products Click Here
